24 AWG stranded (7×32) tinned copper conductors, polyethylene insulation, 1 twisted pair, overall 1XTech® Aluminum Mylar Foil Shield (100% coverage) + tinned copper braid shield (90% coverage), 24 AWG stranded tinned copper drain wire, PVC jacket.

Scientifically designed and proven for use in place of Belden 9841 cable.



Do you require a price on Belden 9841 Cable or Equal Today?

Our goal is to respond to you within 60 seconds.  [Test us!]

Thanks for the opportunity.









Belden 9841 Cable English PDF Datasheet Specification:  1XB9841EQ

View or Download PDF Spec





Belden 9841 Cable Equivalent Applications:

Communications, Audio, Control, Instrumentation, Remote, Signaling, Power-limited systems. RS-485, DMX-512

Suitable for applications where Belden 9841 has been previously utilized.



Belden 9841 Cable Equivalent Features:

Buy American Act approved: YesMade in the USA.

Oil Resistant, Sunlight resistant Multi-Conductor – EIA Industrial RS-485 PLTC/CM Advanced Computer Cable

Value & Performance results driven substitute for Belden 9841.



Belden 9841 Cable Equivalent Standards:

NEC/UL/CSA/ETL specification: CM  / AWM 2919 (30 V 80°C)

RoHS Compliant:   YES

REACH Compliant:  YES

NRTL Tested to UL / CSA Flame Test:  YES



Cable Manufacturing Specifications: 1XB9841EQ

Size: 24 AWG

Conductor / Pair Count: 1 PR

Number of Strands: 7 x 32

Conductor Material:  Tinned Copper

Inner Conductor Colors: White/Blue Stripe and Blue/White Stripe

Insulation Type: PE – Polyethylene or SR-PVC

Shield Type: 1X Tech® Aluminum Mylar Foil Shield (100% coverage) + TC braid shield (90% coverage)

Jacket Type: PVC – Polyvinyl Chloride

Plenum rated (Y/N): No

Jacket Color Options: Chrome, Violet, or Yellow (RAL 1021)  (Other Colors Available)

Outside Diameter: 0.232 Inches  (Nominal)

Weight: 36 lbs per 1000 Feet

Voltage: 300V RMS (UL type CM),  30 V RMS (UL AWM 2919)

Temperature Rating: UL -30°C To +80°C

Nominal Capacitance: Cond. to Cond: 12.8 pF/ft,    Conductor to Shield: 23.0 pF/ft

Cross Reference:  Belden Part Number 9841
