1X Technologies manufactures and supplies extremely high-quality WINTERFLEX® XLPO Rapid Transit Cable and transit wire, to be used in place of, as a cross-reference to, and a direct equivalent to Exane® 1068 & Polyrad® 600V & 2KV Rapid Transit cables.
1X Technologies WINTERFLEX® Rapid Transit Cable has a high-temperature rating but even more pronounced is the arctic grade low-temperature rating of -55°C. XLPO transit wire has much better resistance to cuts or gashes, crush resistance, and scrape abrasion than rubber, EPR, Neoprene, and Hypalon. It is also more flexible and has better overload characteristics than fluoropolymers. WINTERFLEX® Rapid Transit Cable has good moisture and oil resistance, excellent fire resistance, and low smoke and acid gas generation characteristics.
1X Technologies manufactures and supplies Rapid Transit Cables meeting NEC requirements and used in diesel-electric trains, off-road vehicles, heavy and light-rail cars, freight cars, and industrial wayside equipment. Our Rapid transit wire is a tough, flame retardant construction ideally suited for rugged transportation industry applications.
My WINTERFLEX® Rapid Transit Cable Price ✅
Please fill out the secure form below and be sure to include your quantity required, wire & cable description, and delivery location in your message, and your 1X Technologies representative will respond quickly with your WINTERFLEX® Rapid Transit Cable Price/Pricing/Cost per foot.
WINTERFLEX® Rapid Transit Cables Features & Benefits
- Arctic grade temperature range –55°C to 110°C*
- Quality Thermoset Insulation
- Superior mechanical properties
- Extra Flexible construction
- Flame retardant (Passes all applicable flame tests)
- Excellent fluid/oil resistance
- Moisture, UV, and sunlight resistant
- Equivalent to Exane® & Polyrad® Rapid Transit Cable & Wire
WINTERFLEX® Rapid Transit Cable Performance Standards
- Meets AAR RP-585/S-501
- Insulation IAW ICEA S-66-524 (S-95-658)
- Passes NFPA 130-2014
- Exceeds requirements of UL 1685 (FT4/IEEE 1202 with smoke measurement)
- Exceeds the requirements of 49 CFR Part 238 for flame and smoke requirements (ICEA S-19-81)
- Exceeds the requirements of ASTM E662 inflaming and non-flaming modes
- Exceeds the transit toxicity requirements when tested in accordance with BSS 7239
- Exceeds UL VW-1 flame test
- Exceeds IEEE-383 1974 vertical tray flame test
Rapid Transit Cable Construction
Conductor: Annealed, Tinned copper per ASTM B33, B172, AAR S-501, and AAR RP-585
Insulation: Crosslinked polyolefin, XLPO (colors – as required) *Rated 110°C, 130°C overload, 250°C short circuit
1X Technologies WINTERFLEX® Rapid Transit Cables Specifications & Standards – 600 Volt
|
1XT Product Number |
Wire & Cable Type |
Cond. Size (AWG/ MCM) |
Strands |
Insulation Wall |
Nom. Diameter |
Ampacity* @110°C |
Approx. Weight |
Std. Jacket Color |
|||
|
In |
mm |
In |
mm |
LBS/ 1000 FT |
KG/KM |
||||||
|
1XT-18-600V-RT |
Rapid Transit 600V |
18 |
19/30 |
0.030 |
0.76 |
0.109 |
2.77 |
18 |
10.6 |
15.8 |
Dark Gray |
|
1XT-16-600V-RT |
Rapid Transit 600V |
16 |
19/29 |
0.030 |
0.76 |
0.116 |
2.95 |
24 |
12.6 |
18.8 |
Dark Gray |
|
1XT-14-600V-RT |
Rapid Transit 600V |
14 |
19/27 |
0.030 |
0.76 |
0.129 |
3.28 |
39 |
17.8 |
26.5 |
Dark Gray |
|
1XT-12-600V-RT |
Rapid Transit 600V |
12 |
19/25 |
0.030 |
0.76 |
0.147 |
3.73 |
51 |
26 |
38.8 |
Dark Gray |
|
1XT-10-600V-RT |
Rapid Transit 600V |
10 |
27/24 |
0.030 |
0.76 |
0.178 |
4.52 |
67 |
43.5 |
64.9 |
Dark Gray |
|
1XT-8-600V-RT |
Rapid Transit 600V |
8 |
37/24 |
0.045 |
1.14 |
0.232 |
5.89 |
85 |
63.7 |
95.0 |
Dark Gray |
|
1XT-6-600V-RT |
Rapid Transit 600V |
6 |
61/24 |
0.045 |
1.14 |
0.284 |
7.21 |
120 |
102.0 |
152.1 |
Dark Gray |
|
1XT-5-600V-RT |
Rapid Transit 600V |
5 |
91/24 |
0.045 |
1.14 |
0.330 |
8.38 |
145 |
152.1 |
226.8 |
Dark Gray |
|
1XT-4-600V-RT |
Rapid Transit 600V |
4 |
105/24 |
0.045 |
1.14 |
0.356 |
9.04 |
160 |
169.3 |
252.4 |
Dark Gray |
|
1XT-3-600V-RT |
Rapid Transit 600V |
3 |
125/24 |
0.045 |
1.14 |
0.381 |
9.68 |
180 |
193.7 |
288.8 |
Dark Gray |
|
1XT-2-600V-RT |
Rapid Transit 600V |
2 |
150/24 |
0.045 |
1.14 |
0.411 |
10.44 |
214 |
230.8 |
344.1 |
Dark Gray |
|
1XT-1-600V-RT |
Rapid Transit 600V |
1 |
225/24 |
0.055 |
1.40 |
0.501 |
12.73 |
247 |
347.7 |
518.4 |
Dark Gray |
|
1XT-1/0-600V-RT |
Rapid Transit 600V |
1/0 |
275/24 |
0.055 |
1.40 |
0.541 |
13.74 |
286 |
418.1 |
623.3 |
Dark Gray |
|
1XT-2/0-600V-RT |
Rapid Transit 600V |
2/0 |
325/24 |
0.055 |
1.40 |
0.556 |
14.12 |
329 |
461.5 |
688.1 |
Dark Gray |
|
1XT-3/0-600V-RT |
Rapid Transit 600V |
3/0 |
450/24 |
0.055 |
1.40 |
0.661 |
17.79 |
380 |
658 |
981.0 |
Dark Gray |
|
1XT-4/0-600V-RT |
Rapid Transit 600V |
4/0 |
550/24 |
0.055 |
1.40 |
0.686 |
17.42 |
446 |
762 |
1136.1 |
Dark Gray |
|
1XT-262-600V-RT |
Rapid Transit 600V |
262 |
650/24 |
0.065 |
1.65 |
0.765 |
19.43 |
524 |
904 |
1347.8 |
Dark Gray |
|
1XT-313-600V-RT |
Rapid Transit 600V |
313 |
775/24 |
0.065 |
1.65 |
0.833 |
21.16 |
590 |
1070 |
1595.3 |
Dark Gray |
|
1XT-373-600V-RT |
Rapid Transit 600V |
373 |
925/24 |
0.065 |
1.65 |
0.886 |
22.5 |
657 |
1264 |
1884.5 |
Dark Gray |
|
1XT-444-600V-RT |
Rapid Transit 600V |
444 |
1100/24 |
0.065 |
1.65 |
0.950 |
24.13 |
734 |
1494 |
2227.4 |
Dark Gray |
|
1XT-535-600V-RT |
Rapid Transit 600V |
1325/24 |
0.080 |
2.03 |
1.06 |
26.92 |
828 |
1811 |
2700.0 |
Dark Gray |
|
|
1XT-646-600V-RT |
Rapid Transit 600V |
646 |
1600/24 |
0.080 |
2.03 |
1.152 |
29.26 |
931 |
2164 |
3226.3 |
Dark Gray |
|
1XT-777-600V-RT |
Rapid Transit 600V |
777 |
1925/24 |
0.080 |
2.03 |
1.235 |
31.37 |
1047 |
2592 |
3864.4 |
Dark Gray |
|
1XT-1111-600V-RT |
Rapid Transit 600V |
1111 |
2750/24 |
0.095 |
2.41 |
1.530 |
38.86 |
1254 |
3781 |
5637.1 |
Dark Gray |
1X Technologies WINTERFLEX® Rapid Transit Cables Specifications & Standards – 2kV
|
1XT Product Number |
Wire & Cable Type |
Cond. Size (AWG / MCM) |
Strands |
Insulation Wall |
Nom. Diameter |
Ampacity* @110°C |
Approx. Weight |
Std. Jacket Color |
|||
|
In |
mm |
In |
mm |
LBS/ 1000 FT |
KG/KM |
||||||
|
1XT-18-2KV-RT |
Rapid Transit 2kV |
18 |
19/30 |
0.045 |
1.14 |
0.139 |
3.53 |
18 |
15 |
22.4 |
Dark Gray |
|
1XT-16-2KV-RT |
Rapid Transit 2kV |
16 |
19/29 |
0.045 |
1.14 |
0.146 |
3.71 |
24 |
17 |
25.3 |
Dark Gray |
|
1XT-14-2KV-RT |
Rapid Transit 2kV |
14 |
19/27 |
0.045 |
1.14 |
0.159 |
4.04 |
39 |
22 |
32.8 |
Dark Gray |
|
1XT-12-2KV-RT |
Rapid Transit 2kV |
12 |
19/25 |
0.045 |
1.14 |
0.177 |
4.50 |
51 |
31 |
46.2 |
Dark Gray |
|
1XT-10-2KV-RT |
Rapid Transit 2kV |
10 |
27/24 |
0.045 |
1.14 |
0.208 |
5.28 |
67 |
50 |
74.5 |
Dark Gray |
|
1XT-8-2KV-RT |
Rapid Transit |
8 |
37/24 |
0.055 |
1.40 |
0.252 |
6.40 |
85 |
69 |
102.9 |
Dark Gray |
|
1XT-6-2KV-RT |
Rapid Transit 2kV |
6 |
61/24 |
0.055 |
1.40 |
0.304 |
7.72 |
120 |
108 |
161.0 |
Dark Gray |
|
1XT-5-2KV-RT |
Rapid Transit 2kV |
5 |
91/24 |
0.055 |
1.40 |
0.354 |
8.99 |
145 |
155 |
231.1 |
Dark Gray |
|
1XT-4-2KV-RT |
Rapid Transit 2kV |
4 |
105/24 |
0.055 |
1.40 |
0.376 |
9.55 |
160 |
177 |
263.9 |
Dark Gray |
|
1XT-3-2KV-RT |
Rapid Transit 2kV |
3 |
125/24 |
0.055 |
1.40 |
0.401 |
10.19 |
180 |
202 |
301.2 |
Dark Gray |
|
1XT-2-2KV-RT |
Rapid Transit 2kV |
2 |
150/24 |
0.055 |
1.40 |
0.431 |
10.95 |
214 |
240 |
357.8 |
Dark Gray |
|
1XT-1-2KV-RT |
Rapid Transit 2kV |
1 |
225/24 |
0.065 |
1.65 |
0.523 |
13.28 |
247 |
359 |
535.2 |
Dark Gray |
|
1XT-1/0-2KV-RT |
Rapid Transit 2kV |
1/0 |
275/24 |
0.065 |
1.65 |
0.563 |
14.30 |
286 |
431 |
642.6 |
Dark Gray |
|
1XT-2/0-2KV-RT |
Rapid Transit 2kV |
2/0 |
325/24 |
0.065 |
1.65 |
0.585 |
14.86 |
329 |
478 |
712.7 |
Dark Gray |
|
1XT-3/0-2KV-RT |
Rapid Transit 2kV |
3/0 |
450/24 |
0.065 |
1.65 |
0.683 |
17.35 |
380 |
673 |
1003.4 |
Dark Gray |
|
1XT-4/0-2KV-RT |
Rapid Transit 2kV |
4/0 |
550/24 |
0.065 |
1.65 |
0.708 |
17.98 |
446 |
786 |
1171.9 |
Dark Gray |
|
1XT-262-2KV-RT |
Rapid Transit 2kV |
262 |
650/24 |
0.075 |
1.90 |
0.785 |
19.94 |
524 |
920 |
1371.6 |
Dark Gray |
|
1XT-313-2KV-RT |
Rapid Transit 2kV |
313 |
775/24 |
0.075 |
1.90 |
0.853 |
21.67 |
590 |
1090 |
1625.1 |
Dark Gray |
|
1XT-373-2KV-RT |
Rapid Transit 2kV |
373 |
925/24 |
0.075 |
1.90 |
0.908 |
23.06 |
657 |
1285 |
1915.8 |
Dark Gray |
|
1XT-444-2KV-RT |
Rapid Transit 2kV |
444 |
1100/24 |
0.075 |
1.90 |
0.978 |
24.84 |
734 |
1520 |
2266.2 |
Dark Gray |
|
1XT-535-2KV-RT |
Rapid Transit 2kV |
535 |
1325/24 |
0.090 |
2.29 |
1.085 |
27.56 |
828 |
1850 |
2758.2 |
Dark Gray |
|
1XT-646-2KV-RT |
Rapid Transit 2kV |
646 |
1600/24 |
0.090 |
2.29 |
1.230 |
31.24 |
931 |
2250 |
3354.5 |
Dark Gray |
|
1XT-777-2KV-RT |
Rapid Transit 2kV |
777 |
1925/24 |
0.090 |
2.29 |
1.300 |
33.02 |
1047 |
2655 |
3958.4 |
Dark Gray |
|
1XT-1111-2KV-RT |
Rapid Transit 2kV |
1111 |
2750/24 |
0.120 |
3.05 |
1.580 |
40.13 |
1254 |
3810 |
5680.4 |
Dark Gray |
WINTERFLEX® Rapid Transit Cable Sizes 600V / 2KV (AWG / MCM / KCMIL / MM2)
Rapid Transit Cable Sizes range from 18 AWG to 1111 MCM / 1111 KCMIL – Single Conductor and smaller or larger custom sizes may be manufactured up to 4000 KCMIL per customer request.
18 AWG WINTERFLEX® Transit Cable, 600V/2kV
Conductor Strand: 19/30
Insulation Thickness: 600V 0.030 inches 2kV 0.045 inches
Outside Diameter: 600V 0.109 inches 2kV 0.139 inches
Weight: 0.011 lbs per ft 2kV 0.015 lbs per ft
Ampacity**: 18 @ 110°C
16 AWG WINTERFLEX® Transit Cable, 600V/2kV
Size: 16 AWG
Conductor Strand: 19/29
Insulation Thickness: 600V 0.030 inches 2kV 0.045 inches
Outside Diameter: 600V 0.116 inches 2kV 0.146 inches
Weight: 0.012 lbs per ft 2kV 0.017 lbs per ft
Ampacity**: 24 @ 110°C
14 AWG WINTERFLEX® Transit Cable, 600V/2kV
Conductor Strand: 19/27
Insulation Thickness: 600V 0.030 inches 2kV 0.045 inches
Outside Diameter: 600V 0.129 inches 2kV 0.159 inches
Weight: 600v 0.018 lbs per ft 2kV 0.022 lbs per ft
Ampacity**: 39 @ 110°C
12 AWG WINTERFLEX® Transit Cable, 600V/2kV
Size: 12 AWG
Conductor Strand: 19/25
Insulation Thickness: 600V 0.030 inches 2kVV 0.045 inches
Outside Diameter: 0.147 inches
Weight: 0.026 lbs per ft
Ampacity**: 51 @ 110°C
10 AWG WINTERFLEX® Transit Cable, 600V/2kV
Size: 10 AWG
Conductor Strand: 27/24
Insulation Thickness: 0.030 inches
Outside Diameter: 0.178 inches
Weight: 0.0435 lbs per ft
Ampacity**: 67 @ 110°C
8 AWG WINTERFLEX® Transit Cable, 600V/2kV
Size: 8 AWG
Conductor Strand: 37/24
Insulation Thickness: 0.045 inches
Outside Diameter: 0.232 inches
Weight: 0.637 lbs per ft
Ampacity**: 85 @ 110°C
6 AWG WINTERFLEX® Transit Cable, 600V/2kV
Size: 6 AWG
Conductor Strand: 61/24
Insulation Thickness: 0.045 inches
Outside Diameter: 0.284 inches
Weight: 0.102 lbs per ft
Ampacity**: 120 @ 110°C
4 AWG WINTERFLEX® Transit Cable, 600V/2kV
Size: 4 AWG
Conductor Strand: 105/24
Insulation Thickness: 0.045 inches
Outside Diameter: 0.356 inches
Weight: 0.168 lbs per ft
Ampacity**: 160 @ 110°C
2 AWG WINTERFLEX® Transit Cable, 600V/2kV
Size: 2 AWG
Conductor Strand: 105/24
Insulation Thickness: 0.045 inches
Outside Diameter: 0.411 inches
Weight: 0.230 lbs per ft
Ampacity**: 214 @ 110°C
1 AWG WINTERFLEX® Transit Cable, 600V/2kV
Size: 1 AWG
Conductor Strand: 225/24
Insulation Thickness: 0.055 inches
Outside Diameter: 0.501 inches
Weight: 0.347 lbs per ft
Ampacity**: 247 @ 110°C
1/0 WINTERFLEX® Transit Cable, 600V/2kV
Size: 1/0
Conductor Strand: 275/24
Insulation Thickness: 0.055 inches
Outside Diameter: 0.541 inches
Weight: 0.418 lbs per ft
Ampacity**: 286 @ 110°C
2/0 WINTERFLEX® Transit Cable, 600V/2kV
Size: 2/0
Conductor Strand: 325/24
Insulation Thickness: 0.055 inches
Outside Diameter: 0.556 inches
Weight: 0.461 lbs per ft
Ampacity**: 329 @ 110°C
3/0 WINTERFLEX® Transit Cable, 600V/2kV
Size: 3/0
Conductor Strand: 450/24
Insulation Thickness: 0.055 inches
Outside Diameter: 0.661 inches
Weight: 0.658 lbs per ft
Ampacity**: 380 @ 110°C
4/0 WINTERFLEX® Transit Cable, 600V/2kV
Size: 4/0
Conductor Strand: 550/24
Insulation Thickness: 0.055 inches
Outside Diameter: 0.686 inches
Weight: 0.762 lbs per ft
Ampacity**: 446 @ 110°C
262 MCM WINTERFLEX® Transit Cable, 600V/2kV
Size: 262
Conductor Strand: 650/24
Insulation Thickness: 0.065 inches
Outside Diameter: 0.765 inches
Weight: 0.904 lbs per ft
Ampacity**: 524 @ 110°C
313 MCM WINTERFLEX® Transit Cable, 600V/2kV
Size: 313
Conductor Strand: 775/24
Insulation Thickness: 0.065 inches
Outside Diameter: 0.833 inches
Weight: 1.07 lbs per ft
Ampacity**: 590 @ 110°C
373 MCM WINTERFLEX® Transit Cable, 600V/2kV
Size: 373
Conductor Strand: 925/24
Insulation Thickness: 0.065 inches
Outside Diameter: 0.886 inches
Weight: 1.264 lbs per ft
Ampacity**: 657 @ 110°C
444 MCM WINTERFLEX® Transit Cable, 600V/2kV
Size: 444
Conductor Strand: 1100/24
Insulation Thickness: 0.065 inches
Outside Diameter: 0.950 inches
Weight: 1.494 lbs per ft
Ampacity**: 734 @ 110°C
535 MCM WINTERFLEX® Transit Cable, 600V/2kV
Size: 535
Conductor Strand: 1325/24
Insulation Thickness: 0.080 inches
Outside Diameter: 1.06 inches
Weight: 1.811 lbs per ft
Ampacity**: 828 @ 110°C
646 MCM WINTERFLEX® Transit Cable, 600V/2kV
Size: 646
Conductor Strand: 1600/24
Insulation Thickness: 0.080 inches
Outside Diameter: 1.152 inches
Weight: 2.164 lbs per ft
Ampacity**: 931 @ 110°C
777 MCM WINTERFLEX® Transit Cable, 600V/2kV
Size: 777
Conductor Strand: 1925/24
Insulation Thickness: 0.080 inches
Outside Diameter: 1.235 inches
Weight: 2.592 lbs per ft
Ampacity**: 1047 @ 110°C
1111 MCM WINTERFLEX® Transit Cable, 600V/2kV
Size: 1111
Conductor Strand: 2750/24
Insulation Thickness: 0.095 inches
Outside Diameter: 1.530 inches
Weight: 3.781 lbs per ft
Ampacity**: 1254 @ 110°C
