1X Technologies 535 DLO Cable – 2KV

1X Technologies 535 DLO Cable  (Diesel Locomotive Cable) is an extra flexible tinned copper, rubber insulated (EPR), and rubber jacketed (CPE), 2000 volt UL rated specialty cable. We supply you with more common types of DLO cable through great manufacturers like Southwire, Telefonica, and General Cable. When a more specialized or non-stock size, color, or construction is needed we manufacture exactly what you need.

Initially, 535 DLO Cable was designed for use on the electric of powering Diesel Locomotives. Today DLO cable can be used in many other applications. Today 535 DLO Cable is commonly used in place of Welding Cable, and in areas where lesser wires & cables like standard THHN or XHHW will not do the job as effectively.



Request a price on 535 DLO Cable

To help you quickly, let us know these three things in your message:

  • How much 535 DLO Cable do you need?
  • Where will your order deliver?
  • When would you like it delivered?









1X Technologies 535 DLO Cable Engineering Specification



Manufacturer “EZ” Part Number: 1XT-DLO-RHW-535

Description:

1XTech® 2000V 535.3 RHH-RHW-2 Diesel Locomotive Cable (DLO), 1332 x 24 AWG flexible stranded tinned copper conductors, Heavy Duty EPDM Insulation, Black CPE Jacket. Excellent impact and abrasion resistance. Resists oils, acids, alkalies, heat and flame.


Applications:

1XTech® 535.3 DLO Cable may be used in Diesel-electric locomotives, Telecom power supply systems, Oil and gas drilling rigs, Mining and earth moving equipment, Motor leads, Shipyards, Where flexible power leads must be installed in conduit or raceways, Sizes 1/0 and Larger Rated TC-ER, FT4, for Use in Cable Tray. Due to 1XTech® DLO cable carrying a UL RHH/RHW-2 or CSA RW90 rating, the AHJ (authority having jurisdiction) will allow its use in many other applications.

Standards:

  • ICEA S-95-658/ NEMA WC-70: Non-Shielded Power Cables Rated 2000 Volts or Less for the Distribution of Electrical Energy
  • UL Standard 44: Thermoset Insulated Wires & Cables, Types RHH, RHW-2. UL VW-1
  • UL Standard 1685: Vertical Tray Fire propagation and Smoke Release Test for Electrical and optical Fiber Cables. (UL,ST-1)
  • ASTM B-33: Standard Specification for Tinned Soft or Annealed Copper Wire for Electrical Purposes
  • ASTM B-172: Standard Specification for Rope-Lay-Stranded Copper Conductors having Bunch-Stranded Members, for Electrical Conductors
  • MSHA P-184
  • Flame Test: Yes – Passes all applicable flame tests including UL
  • OSHA Compliant
  • RoHS Compliant



1XTech® Manufacturing Specifications: 1XT-DLO-RHW-535

Size: 535.3 AWG

Conductor Count: 1C

Conductor Stranding:  1332 x 24 AWG

Conductor Material: Stranded tinned copper, annealed per AAR 589

Insulation Type: Premium grade EPDM

Jacket Type: Chlorinated Polyethylene TS-CPE polyamide, Nylon outer covering per UL-1063 and UL-83.

Jacket Color:  Black

Outside Diameter: 1.24 inches  (Nominal)

Weight: 2099 lbs per 1000 Feet

Voltage: 2000 Volts / 2KV

Temperature Rating: 90C

Amperage: 725 Amps
