1XTech® Yellow SOOW Cord 600V | Yellow SJOOW Cord 300V Manufacturers, Specifications, Amps, Pricing/Cost to buy, Types, Sizes, Made in the USA

1X Technologies designs, manufactures, sells, and supports our clients with Yellow Cord SOOW & SJOOW Cable which is used in heavy-duty industrial applications where extreme flexibility and unquestioned durability are required. 600 Volt Yellow SOOW and 300 Volt Yellow SJOOW are portable-cord service cables designed for extra hard usage on industrial equipment, heavy tools, motor and welding leads, power extensions, portable machinery, sound equipment, portable stage lights, marine dockside power, and mining applications.

Constructed of color-coded, synthetic oil, ozone, and water-resistant rubber (EPDM) insulation and an oil-resistant thermoset chlorinated polyethylene (CPE) jacket, SOOW is rated for both indoor and outdoor use. SOOW & SJOOW flexible rubber yellow cords carry 600-volt & 300-volt ratings, respectively, but we can also offer you flexible cord products similar to this, yellow in color, up to 15kV depending on your application. Additionally, we can offer larger sizes and more conductors than the standard list of products we have specified below.

Also Known as Yellow Generator Cord, yellow rubber cord, Yellow wire cord, Yellow SO & SJ Cord, Yellow Flexible Cord, and Extension Cord.

My Yellow Cord SOOW / SJOOW Price ✅

Please fill out the secure form below and be sure to include your quantity required, wire & cable description, and delivery location in your message, and your 1X Technologies representative will respond quickly with your Yellow Cord Pricing/Cost per foot to buy your product today, for a great price.

Name:

Email Address:

Confirm Email Address:

Phone Number:

Message:

Send me a copy:

If you still have questions, call us at 1-888-651-9990. We are available to answer questions Monday through Friday, 9 am – 6 pm MST.

Features, Benefits, and Advantages of 1XTech® Yellow SOOW & SJOOW:

Yellow Cord SOOW & SJOOW offers many benefits including

Excellent resistance to oils, acids, chemicals, water, ozone, extreme temperatures, cuts, tears, and abrasion
Sunlight resistant
Flame retardant
Indoor/outdoor rated
Highly flexible
Maximum continuous conductor temperature: 90°C DRY

SOOW & SJOOW meets the following Industry Standards:

UL Flexible Cord Subject 62
CSA Flexible Cord C22.2-49
MSHA Approved
RoHS Compliant
OSHA Acceptable

Yellow Cord, Portable/ Service Cord Defined

YW = Yellow Colored Jacket

S = Service Cord (600V)

SJ = Service Cord Junior (300V)

E = Elastomer

T = Thermoplastic

O = Oil-resistant Outer Jacket

OO = Oil-resistant Outer Jacket and Conductor Jacket

W = Water Resistant/ Weather Resistant

Yellow Cord SJOOW Sizes, Specifications, and Manufacturers Data – 300V

Below you will find many of our top stock sizes for Yellow Cord SJOOW 300V both AWG and MM2.

18/2 SJOOW Yellow Portable Cord 300V UL/CSA

18 AWG 2C Yellow SJOOW Size: 18 AWG
18-2C SJ CORD EU Metric MM2 size: 0.82 MM2 x 2 Conductor
Number of Conductors: 2
Conductor Strand: 41/34
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 7.87 mm / 0.310 inches
Weight: 0.056 lbs per ft
Current Amperage / Ampacity: 10 Amps
Color Code: 2 Conductors: Black, White,
Pricing: My price / Cost per foot on 18 AWG 2C SJOOW YELLOW

18/3 SJOOW Yellow Portable Cord 300V UL/CSA

18 AWG 3C Yellow SJOOW Size: 18 AWG
18-3C SJ CORD EU Metric MM2 size: 0.82 MM2 x 3 Conductor
Number of Conductors: 3
Conductor Strand: 16/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 7.75 mm / 0.305 inches
Weight: 0.063 lbs per ft
Current Amperage / Ampacity: 10 Amps
Color Code: 3 Conductors: Black, White, Green
Pricing: My price / Cost per foot on 18 AWG 3C SJOOW YELLOW

18/4 SJOOW Yellow Portable Cord 300V UL/CSA

18 AWG 4C Yellow SJOOW Size: 18 AWG
18-4C SJ CORD EU Metric MM2 size: 0.82 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 16/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 8.38 mm / 0.330 inches
Weight: 0.076 lbs per ft
Current Amperage / Ampacity: 7 Amps
Color Code: 4 Conductors: Black, White, Red, Green
Pricing: My price / Cost per foot on 18 AWG 4C SJOOW YELLOW

18/5 SJOOW Yellow Portable Cord 300V UL/CSA

18 AWG 5C Yellow SJOOW Size: 18 AWG
18-5C SJ CORD EU Metric MM2 size: 0.82 MM2 x 5 Conductor
Number of Conductors: 5
Conductor Strand: 16/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 8.38 mm / 0.390 inches
Weight: 0.086 lbs per ft
Current Amperage / Ampacity: 7 Amps
Color Code: 5 Conductors: Black, White, Red, Green, Orange
Pricing: My price / Cost per foot on 18 AWG 5C SJOOW YELLOW

16/2 SJOOW Yellow Portable Cord 300V UL/CSA

16 AWG 2C Yellow SJOOW Size: 16 AWG
16-2C SJ CORD EU Metric MM2 size: 1.3 MM2 x 2 Conductor
Number of Conductors: 2
Conductor Strand: 26/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 7.87 mm / 0.310 inches
Weight: 0.06 lbs per ft
Current Amperage / Ampacity: 13 Amps
Color Code: 2 Conductors: Black, White
Pricing: My price / Cost per foot on 16 AWG 2C SJOOW YELLOW

16/3 SJOOW Yellow Portable Cord 300V UL/CSA

16 AWG 3C Yellow SJOOW Size: 16 AWG
16-3C SJ CORD EU Metric MM2 size: 1.3 MM2 x 3 Conductor
Number of Conductors: 3
Conductor Strand: 26/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 8.38 mm / 0.330 inches
Weight: 0.076 lbs per ft
Current Amperage / Ampacity: 13 Amps
Color Code: 3 Conductors: Black, White, Green
Pricing: My price / Cost per foot on 16 AWG 3C SJOOW YELLOW

16/4 SJOOW Yellow Portable Cord 300V UL/CSA

16 AWG 4C Yellow SJOOW Size: 16 AWG
16-4C SJ CORD EU Metric MM2 size: 1.3 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 26/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 9.27 mm / 0.365 inches
Weight: 0.095 lbs per ft
Current Amperage / Ampacity: 10 Amps
Color Code: 4 Conductors: Black, White, Red, Green
Pricing: My price / Cost per foot on 16 AWG 4C SJOOW YELLOW

14/3 SJOOW Yellow Portable Cord 300V UL/CSA

14 AWG 3C Yellow SJOOW Size: 14 AWG
14-3C SJ CORD EU Metric MM2 size: 2.1 MM2 x 3 Conductor
Number of Conductors: 3
Conductor Strand: 41/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 9.40 mm / 0.370 inches
Weight: 0.106 lbs per ft
Current Amperage / Ampacity: 18 Amps
Color Code: 3 Conductors: Black, White, Green
Pricing: My price / Cost per foot on 14 AWG 3C SJOOW YELLOW

14/4 SJOOW Yellow Portable Cord 300V UL/CSA

14 AWG 4C Yellow SJOOW Size: 14 AWG
14-4C SJ CORD EU Metric MM2 size: 2.1 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 41/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 10.41 mm / 0.410 inches
Weight: 0.121 lbs per ft
Current Amperage / Ampacity: 15 Amps
Color Code: 4 Conductors: Black, White, Red, Green
Pricing: My price / Cost per foot on 14 AWG 4C SJOOW YELLOW

12/3 SJOOW Yellow Portable Cord 300V UL/CSA

12 AWG 3C Yellow SJOOW Size: 12 AWG
12-3C SJ CORD EU Metric MM2 size: 3.3 MM2 x 3 Conductor
Number of Conductors: 3
Conductor Strand: 65/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 10.92 mm / 0.430 inches
Weight: 0.146 lbs per ft
Current Amperage / Ampacity: 25 Amps
Color Code: 3 Conductors – Black, White, Green
Pricing: My price / Cost per foot on 12 AWG 3C SJOOW YELLOW

12/4 SJOOW Yellow Portable Cord 300V UL/CSA

12 AWG 4C Yellow SJOOW Size: 12 AWG
12-4C SJ CORD EU Metric MM2 size: 3.3 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 65/30
Insulation Thickness: 0.76 mm / 0.030 inches
Outside Diameter: 12.07 mm / 0.475 inches
Weight: 0.185 lbs per ft
Current Amperage / Ampacity: 20 Amps
Color Code: 4 Conductors: Black, White, Red, Green
Pricing: My price / Cost per foot on 12 AWG 4C SJOOW YELLOW

Yellow Cord SOOW Sizes – 600V

Below you will find many of our top stock sizes for Yellow Cord SOOW 600V both AWG and MM2.

18/3 SOOW Yellow Portable Cord 600V UL/CSA

18 AWG 3C Yellow SOOW Size: 18 AWG
18-3C SO CORD EU Metric MM2 size: 0.82 MM2 x 3 Conductor
Number of Conductors: 3
Conductor Strand: 16/30
Insulation Thickness: 0.030 inches
Outside Diameter: 0.365 inches
Weight: 0.084 lbs per ft
Current Amperage / Ampacity: 10 Amps
Color Code: 3 Conductors – Black, White, Green
Pricing: My price / Cost per foot on 18 AWG 3C SOOW YELLOW

18/4 SOOW Yellow Portable Cord 600V UL/CSA

18 AWG 4C Yellow SOOW Size: 18 AWG
18-4C SO CORD EU Metric MM2 size: 0.82 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 16/30
Insulation Thickness: 0.030 inches
Outside Diameter: 0.390 inches
Weight: 0.101 lbs per ft
Current Amperage / Ampacity: 7 Amps
Color Code: 4 Conductors – Black, White, Red, Green
Pricing: My price / Cost per foot on 18 AWG 4C SOOW YELLOW

18/5 SOOW Yellow Portable Cord 600V UL/CSA

18 AWG 5C Yellow SOOW Size: 18 AWG
18-5C SO CORD EU Metric MM2 size: 0.82 MM2 x 5 Conductor
Number of Conductors: 5
Conductor Strand: 16/30
Insulation Thickness: 0.030 inches
Outside Diameter: 0.465 inches
Weight: 0.141 lbs per ft
Current Amperage / Ampacity: 5.6 Amps
Color Code: 5 Conductors – Black, White, Red, Green, Orange
Pricing: My price / Cost per foot on 18 AWG 5C SOOW YELLOW

16/3 SOOW Yellow Portable Cord 600V UL/CSA

16 AWG 3C Yellow SOOW Size: 16 AWG
16-3C SO CORD EU Metric MM2 size: 1.3 MM2 x 3 Conductor
Number of Conductors: 3
Conductor Strand: 26/30
Insulation Thickness: 0.030 inches
Outside Diameter: 0.390 inches
Weight: 0.103 lbs per ft
Current Amperage / Ampacity: 13 Amps
Color Code: 3 Conductors – Black, White, Green
Pricing: My price / Cost per foot on 16 AWG 3C SOOW YELLOW

16/4 SOOW Yellow Portable Cord 600V UL/CSA

16 AWG 4C Yellow SOOW Size: 16 AWG
16-4C SO CORD EU Metric MM2 size: 1.3 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 26/30
Insulation Thickness: 0.030 inches
Outside Diameter: 0.420 inches
Weight: 0.119 lbs per ft
Current Amperage / Ampacity: 10 Amps
Color Code: 4 Conductors – Black, White, Red, Green
Pricing: My price / Cost per foot on 16 AWG 4C SOOW YELLOW

14/3 SOOW Yellow Portable Cord 600V UL/CSA

14 AWG 3C Yellow SOOW Size: 14 AWG
14-3C SO CORD EU Metric MM2 size: 2.1 MM2 x 3 Conductor
Number of Conductors: 3
Conductor Strand: 41/30
Insulation Thickness: 0.045 inches
Outside Diameter: 0.535 inches
Weight: 0.172 lbs per ft
Current Amperage / Ampacity: 18 Amps
Color Code: 3 Conductors – Black, White, Green
Pricing: My price / Cost per foot on 14 AWG 3C SOOW YELLOW

14/4 SOOW Yellow Portable Cord 600V UL/CSA

14 AWG 4C Yellow SOOW Size: 14 AWG
14-4C SO CORD EU Metric MM2 size: 2.1 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 41/30
Insulation Thickness: 0.045 inches
Outside Diameter: 0.575 inches
Weight: 0.208 lbs per ft
Current Amperage / Ampacity: 15 Amps
Color Code: 4 Conductors – Black, White, Red, Green
Pricing: My price / Cost per foot on 14 AWG 4C SOOW YELLOW

12/3 SOOW Yellow Portable Cord 600V UL/CSA

12 AWG 3C Yellow SOOW Size: 12 AWG
12-3C SO CORD EU Metric MM2 size: 3.3 MM2 x 3 Conductor
Number of Conductors: 3
Conductor Strand: 65/30
Insulation Thickness: 0.045 inches
Outside Diameter: 0.595 inches
Weight: 0.229 lbs per ft
Current Amperage / Ampacity: 25 Amps
Color Code: 3 Conductors – Black, White, Green
Pricing: My price / Cost per foot on 12 AWG 3C SOOW YELLOW

12/4 SOOW Yellow Portable Cord 600V UL/CSA

12 AWG 4C Yellow SOOW Size: 12 AWG
12-4C SO CORD EU Metric MM2 size: 3.3 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 65/30
Insulation Thickness: 0.045 inches
Outside Diameter: 0.650 inches
Weight: 0.280 lbs per ft
Current Amperage / Ampacity: 20 Amps
Color Code: 4 Conductors – Black, White, Red, Green
Pricing: My price / Cost per foot on 12 AWG 4C SOOW YELLOW

10/3 SOOW Yellow Portable Cord 600V UL/CSA

10 AWG 3C Yellow SOOW Size: 10 AWG
10-3C SO CORD EU Metric MM2 size: 5.3 MM2 x 3 Conductor
Number of Conductors: 3
Conductor Strand: 104/30
Insulation Thickness: 0.045 inches
Outside Diameter: 0.660 inches
Weight: 0.295 lbs per ft
Current Amperage / Ampacity: 30 Amps
Color Code: 3 Conductors – Black, White, Green
Pricing: My price / Cost per foot on 10 AWG 3C SOOW YELLOW

10/4 SOOW Yellow Portable Cord 600V UL/CSA

10 AWG 4C Yellow SOOW Size: 10 AWG
10-4C SO CORD EU Metric MM2 size: 5.3 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 104/30
Insulation Thickness: 0.045 inches
Outside Diameter: 0.715 inches
Weight: 0.353 lbs per ft
Current Amperage / Ampacity: 25 Amps
Color Code: 4 Conductors – Black, White, Red, Green
Pricing: My price / Cost per foot on 10 AWG 4C SOOW YELLOW

8/4 SOOW Yellow Portable Cord 600V Non-UL

8 AWG 4C Yellow SOOW Size: 8 AWG
8-4C SO CORD EU Metric MM2 size: 8.4 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 65/26
Insulation Thickness: 0.050 inches
Outside Diameter: 0.740 inches
Weight: 0.480 lbs per ft
Current Amperage / Ampacity: 35 Amps
Color Code: 4 Conductors – Black, White, Red, Green
Pricing: My price / Cost per foot on 8 AWG 4C SOOW YELLOW

4/4 SOOW Yellow Portable Cord 600V Non-UL

4 AWG 4C Yellow SOOW Size: 4 AWG
4-4C SO CORD EU Metric MM2 size: 21.2 MM2 x 4 Conductor
Number of Conductors: 4
Conductor Strand: 119/25
Insulation Thickness: 0.050 inches
Outside Diameter: 1.030 inches
Weight: 0.845 lbs per ft
Current Amperage / Ampacity: 60 Amps
Color Code: 4 Conductors – Black, White, Red, Green
Pricing: My price / Cost per foot on 4 AWG 4C SOOW YELLOW

Yellow Cord SOOW 600V & SJOOW 300V [Price, Specs, Types, Sizes)
