SRG-G Control Cable – High-Temp 200C Wire & Cables [Specs/Pricing]

1XTech SRG-G Control Cable 600V Temp Rating 200°C Manufacturers Suppliers Price cost to buy

1XTech® SRG-G Control Cable, High-Temperature High-Heat 200C 600V Multi-Conductor, Manufacturers Specifications, Amps, Pricing/Cost to buy, Types, Sizes, High-Temp SRG-G Wire & Cables Made in the USA

1X Technologies designs, manufactures, sells, and supports our clients with electrical SRG-G Control Cable which is used in heavy-duty high-temp industrial applications where extreme flexibility and unquestioned durability in high-heat environments are required. 600 Volt SRG-G Control Cables are designed for extra high-temperature usage on wiring your equipment.
 Additionally, we can offer you larger sizes and more conductors than the standard list of products we have specified below and can manufacture your cable in many different color and conductor options, as well as offer you customizations such as Armored SRG-G Control Cable, Shielded, Cable-In-Conduit, and Cable with connectors factory-applied, and even high temp Submersible or Submarine Cables. Contact us below for your price on SRG-G Wires & Cables.

My Quick SRG-G Control Cable Price

Include your quantity required, wire & cable description, and delivery location in your message, and your 1X Technologies representative will respond quickly with your SRG-G Wire & Cable Pricing.





If you still have questions, call us at 1-888-651-9990. We are available to answer questions Monday through Friday, 9 am – 6 pm MST.





SRG-G Control Cable Specifications / Manufacturing Specs

SRG-G Control Cable Construction:

  1. Conductor: Stranded tinned, annealed copper per ASTM B33
  2. Insulation: Silicone Rubber with a fiberglass braid over the insulation
  3. Cabling: Conductors are cabled with a left-hand lay and bound with a polyester tape
  4. Jacket: Fiberglass braid, treated with a high-temperature saturant, covers the core



SRG-G Control Cable



Applications, Uses, and Features of SRG-G Control Cable:

  • Used for equipment wiring, as well as signal and control circuits. Ideal in locations where high temperature or hazardous conditions exist that require heat resistance at 600 volts.
  • Fiberglass Jacket provides improved mechanical strength and abrasion resistance. Flexible. Good chemical strength. Excellent electrical properties. Passes IEEE 383 70,000 BTU/Hr Flame test while maintaining circuit integrity.



SRG-G Control Cable Specifications:

  • ASTM B33 Standard Specification for Tin-Coated Soft or Annealed Copper Wire
  • IEEE 383 Flame Test (70,000 BTU)
  • RoHS-3 Complies with European Directive 2015/863





16 AWG SRG-G Control Cable 200C Specs (7/.0192) .030 INSULATION

# COND BRAID
JACKET
CABLE
OD
WEIGHT
LBS / MFT
TEMP
RATING
2 .040 0.345 43 200°C
3 .040 0.360 60 200°C
4 .040 0.400 75 200°C
5 .040 0.435 95 200°C
7 .040 0.475 130 200°C
9 .040 0.555 165 200°C
12 .040 0.625 220 200°C
19 .040 0.735 350 200°C
24 .040 0.865 440 200°C
37 .040 0.995 660 200°C

14 AWG SRG-G Control Cable 200C Specs (7/.0242) .030 INSULATION

# COND BRAID
JACKET
CABLE
OD
WEIGHT
LBS / MFT
TEMP
RATING
2 .040 0.375 55 200°C
3 .040 0.400 75 200°C
4 .040 0.435 100 200°C
5 .040 0.480 125 200°C
7 .040 0.520 170 200°C
9 .040 0.610 210 200°C
12 .040 0.690 280 200°C
19 .040 0.810 415 200°C
24 .040 0.955 525 200°C

12 AWG SRG-G Control Cable 200C Specs (19/.0179) .030 INSULATION

# COND BRAID
JACKET
CABLE
OD
WEIGHT
LBS / MFT
TEMP
RATING
2 .040 0.410 75 200°C
3 .040 0.430 110 200°C
4 .040 0.475 145 200°C
5 .040 0.520 175 200°C
7 .040 0.570 240 200°C
9 .040 0.670 300 200°C
12 .040 0.755 410 200°C
19 .040 0.890 625 200°C
24 .040 1.045 812 200°C

10 AWG SRG-G Control Cable 200C Specs (19/.0234) .045 INSULATION

# COND BRAID
JACKET
CABLE
OD
WEIGHT
LBS / MFT
TEMP
RATING
2 .040 0.525 125 200°C
3 .040 0.555 180 200°C
4 .040 0.615 235 200°C
5 .040 0.675 300 200°C
7 .040 0.740 385 200°C
9 .040 0.875 500 200°C
12 .040 0.990 665 200°C





SRG-G Control Cable PDF SPECIFICATIONS

Contact your 1X Technologies sales representative to obtain PDF specifications including Amps, O.D., and other pertinent information for your submittal.









Belden SRG-G Control Cable High Temp Equals/Equivalents

1X Technologies sells equals to Belden SRG-G Control Cable Equals in all sizes and color combinations for your high-temperature applications. Contact us today if you need an alternative to Belden high-temp cable.
