1XTech® SRG-G Power Cable, High-Temperature High-Heat 200C 600V Multi-Conductor 8 AWG – 6 AWG, Manufacturers Specifications, Amps, Pricing/Cost to buy, Types, Sizes, High-Temp SRG-G Wire & Cables Made in the USA
My Quick SRG-G Power Cable Price ✅
Include your quantity required, wire & cable description, and delivery location in your message, and your 1X Technologies representative will respond quickly with your SRG-G Wire & Cable Pricing.
If you still have questions, call us at 1-888-651-9990. We are available to answer questions Monday through Friday, 9 am – 6 pm MST.
SRG-G Power Cable Specifications / Manufacturing Specs
Construction:
- Conductor: Stranded tinned, annealed copper per ASTM B33
- Insulation: Silicone Rubber with a fiberglass braid over the insulation
- Cabling: Conductors are cabled with a left-hand lay and bound with a polyester tape
- Jacket: Fiberglass braid, treated with a high-temperature saturant, covers the core
Applications and Features:
- Used for equipment wiring, as well as signal and power circuits. Ideal in locations where high temperature or hazardous conditions exist that require heat resistance at 600 volts.
- Fiberglass Jacket provides improved mechanical strength and abrasion resistance. Flexible. Good chemical strength. Excellent electrical properties. Passes IEEE 383 70,000 BTU/Hr Flame test while maintaining circuit integrity.
Specifications:
- ASTM B33 Standard Specification for Tin-Coated Soft or Annealed Copper Wire
- IEEE 383 Flame Test (70,000 BTU)
- RoHS-3 Complies with European Directive 2015/863
SRG-G Power Cable Specs – Weights and Measurements
| 1XTECH Stock Number | Size | Cond. # | OD | Weight | Temp. Rating |
|---|---|---|---|---|---|
| AWG/
Kcmil |
No. | inch | lb/1000ft | °C | |
| SRGG-P82 | 8 | 2 | 0.620 | 180 | 200 |
| SRGG-P83 | 8 | 3 | 0.660 | 265 | 200 |
| SRGG-P84 | 8 | 4 | 0.750 | 350 | 200 |
| SRGG-P62 | 6 | 2 | 0.675 | 250 | 200 |
| SRGG-P63 | 6 | 3 | 0.730 | 355 | 200 |
SRG-G Power Cable PDF SPECIFICATIONS
Contact your 1X Technologies sales representative to obtain PDF specifications including Amps, O.D., and other pertinent information for your submittal.
Belden SRG-G Power Cable High Temp Equals/Equivalents
1X Technologies sells equals to Belden SRG-G Power Cable Equals in all sizes and color combinations for your high-temperature applications. Contact us today if you need an alternative to Belden high-temp cable.
